| GS Strip thickness | 0.4-0.8mm | |
| GS Strip width | 50-150mm | |
| Fireproof fabric strip width | 100-300mm | |
| Final production strip width | 140-540mm | |
|
Power |
Main | 3kw (Inverter motor) |
| Hydraulic station | 7.5kw | |
| Servo motor | 0.75kw | |
| Speed | 0-10m/min | |
| Weight | 2500kg | |
| Dimension | 3000*1500*1600mm | |
|
Configuration |
1.Holes punched by the hydraulic unit 2.Hydraulic driven auto cutting 3.Encoder from Japanese OMRON PLC &frequency converter from DELTA Electrical equipment from Schneider All hydraulic cylinder and accessory from Taiwan 4.Decoiler(Load:＜800kg) 2 sets Hydraulic servo feeder 1 sets Hydraulic punching moulds 2 sets Main machine 1 set Receiving rack 1 set |
|
