Round Flange Forming Machine


Partial view




Technical Data

Type SBJY-50 SBJY-80
Angle iron  specification 3#/4#/5# 6#/7#/8#
Min. machining diameter ¢≥600≥500≥350 ¢≥700≥1200≥1800
Flat bar specification 3#/4#/5# 6#/7#/8#
Working Speed 2m/min 1.5m/min
Power 2.2kw 4kw
Weight 355kg 960kg
Dimension 820*490*750mm 1200*1000*1050mm
